Tractors > John Deere > 1R 25

John Deere 1R 25



John Deere 1R 25 tractor photo
2027 -
1 Series
Sub-Compact Utility tractor
Series map:
1M 25
1R 25
23.2hp
23.2hp
Production
ManufacturerJohn Deere
Sub-Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 1R 25 Engine
Yanmar 1.3L 3-cyl diesel
Fuel tank5.31 gal
20.1 L
Engine details ...
John Deere 1R 25 Transmission
hydrostatic
Transmission details ...
John Deere 1R 25 Power
Engine (gross)23.2 hp
17.3 kW
PTO (claimed)17.8 hp
13.3 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional with available air-conditioning.
Photos
No photos of the John Deere 1R 25 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow3.5 gpm
13.2 lpm
Total flow7 gpm
26.5 lpm
Steering flow3.5 gpm
13.2 lpm
Tractor hitch
Rear TypeI (limited)
Controlpostion control
Rear lift (at 24"/610mm)915 lbs
415 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2100
Dimensions & Tires
Wheelbase63 inches
160 cm
Weight1797 to 2242 pounds
Full dimensions and tires ...
John Deere 1R 25 attachments
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery CCA500
Battery volts12
References
1R 25 references literature
1 Series Sub-Compact Utility Tractors published in 2026, by John Deere
