CaseIH Magnum 405



CaseIH Magnum 405 tractor photo
2025 -
Magnum Series
Row-Crop tractor
Series map:
Magnum 385
Magnum 405
385.0hp
405.0hp
Production
ManufacturerCaseIH (a part of CNH)
Row-Crop tractor
Built in Racine, Wisconsin, USA
Original price was $660,127 in 2026
Variants
405 Rowtrachalf-track
CaseIH Magnum 405 Engine
FPT 8.7L 6-cyl diesel
Fuel tank179 gal
677.5 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
CaseIH Magnum 405 Transmission
21-speed full power shift
Transmission details ...
CaseIH Magnum 405 Power
Engine (gross)405 hp
302.0 kW
Engine (max)435 hp
324.4 kW
Engine (boost)435 hp
324.4 kW
PTO (claimed)352 hp
262.5 kW
Mechanical
Four-wheel drive
Differential lockelectronic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Magnum 405 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensating
Valves5 or 6
Pump flow59 gpm
223.3 lpm
 86 gpmOptOptional
325.5 lpm
Tractor hitch
Rear TypeIV/III
Rear lift19900 lbs
9026 kg
Front lift9426 lbs
4275 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Front PTOindependent
Front PTO Type1000 (1.375)
 1000 (1.75)
Dimensions & Tires
Wheelbase124 inches
314 cm
Weight32200 lbs
14605 kg
Front tire420/85R34
Rear tire480/80R50
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery volts12
References
Magnum 405 references literature
Magnum published in 2025, by CaseIH
