John Deere 5600
1996 - 1999 Utility tractor
Series map:
5600
5700
55.9kw
63.4kw
Production Manufacturer John Deere
Utility tractor Built in Horizontina, Brazil
John Deere 5600 Power Engine 75 hp55.9 kW
PTO (claimed) 64 hp47.7 kW
Mechanical Two- or four-wheel drive Differential lock mechanical rear
Power steering Hydraulic wet disc brakes ROPS.
Photos No photos of the John Deere 5600 are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Hydraulics Type open center
Pump flow 10.6 gpm40.1 lpm
Tractor hitch Rear Type II
Control top-link draft sensing
Rear lift (at 24"/610mm) 3968 lbs1799 kg
Power Take-off (PTO) Rear PTO independent
Rear PTO Type 540 (1.375)
Electrical Ground negative
Charging amps 52
Charging volts alternator
Battery CCA 700
Battery volts 12
Battery AH 100
References Operator's Manual 5600 and 5700 Tractors (OMCQ26831) published in 1998
Page information Copyright 2025 TractorData.com® Email me: Peter@TractorData.com TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. Peter Easterlund - owner/authorThis machine's data modified on November 30, 2025
©2000-2025 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
