Tractors > CaseIH > Steiger 475

CaseIH Steiger 475



CaseIH Steiger 475 tractor photo
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 425
Steiger 475
Steiger 525
419.2hp
468.5hp
517.8hp
Production
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $701,209 in 2026
Variants
T9.520similar New Holland model
CaseIH Steiger 475 Engine
FPT 12.9L 6-cyl diesel
Fuel tank310 gal
1173.4 L
Exhaust fluid (DEF)42 gal
159.0 L
Engine details ...
CaseIH Steiger 475 Transmissions
17-speed full power shift
continuously-variable transmission
Transmission details ...
CaseIH Steiger 475 Power
Engine (gross)468.5 hp
349.4 kW
Engine (max)514.9 hp
384.0 kW
PTO (claimed)455.7 hp
339.8 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockautomatic front and rear
Articulated power steering
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 475 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN/III
Rear lift (at 24"/610mm)21903 lbs
9935 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase148 inches
375 cm
Weight40800 lbs
18506 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
 330 OptOptional
Batteries3
Battery CCA950
Battery volts12
References
Steiger 475 references literature
AFS Connect Steiger published in 2024, by CNH Industrial
Steiger published in 2024, by CNH Industrial
