Tractors > CaseIH > Steiger 470

CaseIH Steiger 470



CaseIH Steiger 470 tractor photo
2014 - 2023
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 420
Steiger 470
Steiger 500
420.0hp
470.0hp
500.0hp
Production
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $378,190 in 2015
Variants
470wheeled tractor
470RTrow-crop crawler
470QTcrawler
T9.530similar New Holland model
CaseIH Steiger 470 Engine
FPT 12.9L 6-cyl diesel
Fuel tank310 gal
1173.4 L
Exhaust fluid (DEF)42 gal
159.0 L
Engine details ...
CaseIH Steiger 470 Transmission
16-speed full power shift
Transmission details ...
CaseIH Steiger 470 Power
Engine470 hp
350.5 kW
PTO (claimed)405 hp
302.0 kW
Drawbar (tested)387.67 hp
289.1 kW
PTO (tested)468.35 hp
349.2 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Steeringhydraulic articulated
Brakeshydraulic wet disc
 engine brake OptOptional
Trailer brakeshydraulic OptOptional
Surveyor Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 470 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensated
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpm*High Flow option
215.7 lpm
 113 gpm*TwinFlow option
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)20000 lbs
9072 kg
Rear Armsquick coupler
DrawbarCat. 4
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@1998 (early)
 1000@1811 (late)
Dimensions & Tires
Wheelbase148 inches
375 cm
Weight40159 lbs
18216 kg
Front tire710/70R42
Rear tire710/70R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA1000
Battery volts12
References
Steiger 470 references literature
Steiger 370-620 Tractors published in 2014, by CaseIH
