CaseIH Steiger 425

No photo available
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 425
Steiger 475
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
CaseIH Steiger 425 Engine
FPT 12.9L 6-cyl diesel
Fuel tank310 gal
1173.4 L
Exhaust fluid (DEF)42 gal
159.0 L
Engine details ...
CaseIH Steiger 425 Transmissions
17-speed full power shift
continuously-variable transmission
Transmission details ...
CaseIH Steiger 425 Power
Engine (gross)419.2 hp
312.6 kW
Engine (max)460.6 hp
343.5 kW
PTO (claimed)403.4 hp
300.8 kW
Four-wheel drive
Final drivesplanetary
Differential lockautomatic front and rear
Articulated power steering
Cab standard with air-conditioning.
No photos of the CaseIH Steiger 425 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN/III
Rear lift (at 24"/610mm)21903 lbs
9935 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase148 inches
375 cm
Weight40800 lbs
18506 kg
Full dimensions and tires ...
Charging systemalternator
Charging amps240
 330 OptOptional
Battery CCA950
Battery volts12
Steiger 425 references literature
TAFS Connect Steiger published in 2024, by New Holland
