Massey Ferguson 9S.340


Massey Ferguson 9S.340 tractor photo
2024 -
9S Series
Row-Crop tractor
Series map:
9S.310
9S.340
9S.370
310.0hp
340.0hp
370.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Built in Beauvais, France
Massey Ferguson 9S.340 Engine
AGCO Power 8.4L 6-cyl diesel
Fuel tank174.4 gal
660.1 L
Exhaust fluid (DEF)18 gal
68.1 L
Engine details ...
Massey Ferguson 9S.340 Power
Engine340 hp
253.5 kW
Mechanical
Four-wheel drive
Power steering
Cab standard with air-conditioning.
Photos
No photos of the Massey Ferguson 9S.340 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load sensing
Pressure2900 psi
200.0 bar
Rear valves6 OptOptional
Front valves1 or 2
Pump flow71.3 gpm
269.9 lpm
 105.7 gpmOptOptional
400.1 lpm
Tractor hitch
Rear TypeIV/III
Rear lift (at ends)26455 lbs
11999 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Engine RPM540E@1577
 1000@1882
 1000E@1605
Front PTOindependent
Front PTO Type1000
Engine RPM1000@2036
Dimensions & Tires
Wheelbase122.1 inches
310 cm
Front tire600/70R30
Rear tire650/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
9S.340 references literature
MF 9S - Outstanding design, ultimate performance published in 2023, by Massey Ferguson
