Massey Ferguson 9S.370
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Row-Crop tractor | |
| Built in Beauvais, France | |
| Massey Ferguson 9S.370 Engine | |
| AGCO Power 8.4L 6-cyl diesel | |
| Fuel tank | 174.4 gal 660.1 L |
| Exhaust fluid (DEF) | 18 gal 68.1 L |
 Engine details ... | |
| Massey Ferguson 9S.370 Transmission | |
| continuously variable transmission | |
 Transmission details ... |
| Massey Ferguson 9S.370 Power | |
| Engine | 370 hp 275.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Massey Ferguson 9S.370 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 6 OptOptional |
| Front valves | 1 or 2 |
| Pump flow | 71.3 gpm 269.9 lpm |
| 105.7 gpmOptOptional 400.1 lpm | |
| Tractor hitch | |
| Rear Type | IV/III |
| Rear lift (at ends) | 26455 lbs 11999 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540E@1577 |
| 1000@1882 | |
| 1000E@1605 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Engine RPM | 1000@2036 |
| Dimensions & Tires | |
| Wheelbase | 122.1 inches 310 cm |
| Front tire | 650/60R30 |
| Rear tire | 710/75R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 9S - Outstanding design, ultimate performance published in 2023, by Massey Ferguson |
