Kubota L4802
| | 2022 - |
| L02 Standard Series | | Compact Utility tractor |
|
Series map:
L3902
L4802
37.5hp
48.4hp
| Production |
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Original price | $23,733 (2023)
|
| $24,925 (2026)
|
| Kubota L4802 Power |
| Engine (gross) | 48.4 hp
36.1 kW
|
| Engine (net) | 46.0 hp
34.3 kW
|
| Gear PTO (claimed) | 40.5 hp
30.2 kW
|
| Hydro PTO (claimed) | 39 hp
29.1 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Mechanical wet disc brakes |
| Two-post folding ROPS. |
| Hydraulics |
| Type | open center
|
| Pump flow | 7.8 gpm
29.5 lpm
|
| Steering flow | 4.7 gpm
17.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 2870 lbs
1301 kg
|
| Rear lift (at 24"/610mm) | 2320 lbs
1052 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540L2475 (gear)
|
| | 540@2640 (hydro)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Charging volts | 12
|
| Battery CCA | 600
|
| Battery volts | 12
|
| References |
 |
| L02 Series published in 2022, by Kubota |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on April 6, 2026 |
