Kubota L4802N
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Original price was $34,406 in 2023 | |
| Kubota L4802N Engine | |
| Kubota 2.4L 4-cyl diesel | |
| Fuel tank | 13.5 gal 51.1 L |
 Engine details ... | |
| Kubota L4802N Transmission | |
| hydrostatic | |
 Transmission details ... |
| Kubota L4802N Power | |
| Engine (gross) | 48.4 hp 36.1 kW |
| Engine (net) | 46.0 hp 34.3 kW |
| PTO (claimed) | 40.5 hp 30.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post mid-mount folding ROPS. |
| Photos | |
| No photos of the Kubota L4802N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 7.8 gpm 29.5 lpm |
| Steering flow | 4.7 gpm 17.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 2870 lbs 1301 kg |
| Rear lift (at 24"/610mm) | 2320 lbs 1052 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2640 |
| Dimensions & Tires | |
| Wheelbase | 72.6 inches 184 cm |
| Weight | 3362 lbs 1525 kg |
| Front tire | 7.2-16 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Charging volts | 12 |
| Battery CCA | 600 |
| Battery volts | 12 |
| References | |
 | |
| L02 Series published in 2022, by Kubota |
