Branson 4815CH
| | 2021 - 2023 |
| 15 Series | | Compact Utility tractor |
|
Series map:
4215CH
4815CH
42.0hp
48.0hp
| Production |
| Manufacturer | Branson (a part of TYM)
|
| Compact Utility tractor |
| Branson 4815CH Power |
| Engine | 48 hp
35.8 kW
|
| PTO (claimed) | 40 hp
29.8 kW
|
| Mechanical |
| Power steering |
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Pump flow | 4.4 gpm
16.7 lpm
|
| Total flow | 14.3 gpm
54.1 lpm
|
| Steering flow | 9.9 gpm
37.5 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift | 3306 lbs
1499 kg
|
| Rear lift (at 24"/610mm) | 2425 lbs
1099 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 540 (1.375)
|
| Engine RPM | 560@2600
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 70
|
| Battery volts | 12
|
| References |
 |
| 15 Series Cabs published in 2021, by Branson |
