Branson 4815R


No photo available
2015 - 2023
15 Series
Compact Utility tractor
Production
ManufacturerBranson (a part of TYM)
Compact Utility tractor
Variants
4815Rshuttle
4815Hhydrostatic
4815CHcab
Branson 4815R Power
Engine47 hp
35.0 kW
PTO (claimed)40 hp
29.8 kW
Mechanical
Four-wheel drive
Power steering
Two-post folding ROPS.
Photos
No photos of the Branson 4815R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow8.7 gpm
32.9 lpm
Steering flow4.7 gpm
17.8 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)3306 lbs
1499 kg
Rear lift (at 24"/610mm)2420 lbs
1097 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Dimensions & Tires
Front tire7-16
Rear tire12.4-24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
4815R references literature
15 Series published in 2019, by Branson
