Branson 4215CH
|
|
| Production | |
| Manufacturer | Branson (a part of TYM) |
| Compact Utility tractor | |
| Branson 4215CH Engine | |
| Kukje 2.3L 4-cyl diesel | |
| Fuel tank | 7.1 gal 26.9 L |
 Engine details ... | |
| Branson 4215CH Transmission | |
| hydrostatic | |
 Transmission details ... |
| Branson 4215CH Power | |
| Engine | 42 hp 31.3 kW |
| PTO (claimed) | 36 hp 26.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Branson 4215CH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 11.1 gpm 42.0 lpm |
| Steering flow | 5 gpm 18.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 3306 lbs 1499 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 560@2600 |
| Dimensions & Tires | |
| Wheelbase | 65.7 inches 166 cm |
| Weight | 3664 lbs 1661 kg |
| Front tire | 7-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 15 Series published in 2020, by Branson | |
| 15 Series Cabs published in 2021, by Branson |
