Branson 3515CH
| | 2021 - 2023 |
| 15 Series | | Compact Utility tractor |
|
Series map:
3515CH
4215CH
35.0hp
42.0hp
| Production |
| Manufacturer | Branson (a part of TYM)
|
| Compact Utility tractor |
| Branson 3515CH Power |
| Engine | 35 hp
26.1 kW
|
| PTO (claimed) | 30 hp
22.4 kW
|
| Mechanical |
| Power steering |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Branson 3515CH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 11.1 gpm
42.0 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift | 3306 lbs
1499 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 560@2600
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| 15 Series Cabs published in 2021, by Branson |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 29, 2023 |
