Branson 3515R
|
|
| Production | |
| Manufacturer | Branson (a part of Kukje) |
| Compact Utility tractor | |
| Built in South Korea | |
| Branson 3515R Engine | |
| Kukje 1.7L 3-cyl diesel | |
| Fuel tank | 7 gal 26.5 L |
 Engine details ... | |
| Branson 3515R Transmission | |
| 12-speed synchronized shuttle | |
 Transmission details ... |
| Branson 3515R Power | |
| Engine | 35 hp 26.1 kW |
| PTO (claimed) | 22 hp 16.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Branson 3515R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 8.7 gpm 32.9 lpm |
| Steering flow | 4.7 gpm 17.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 3306 lbs 1499 kg |
| Rear lift (at 24"/610mm) | 2420 lbs 1097 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E |
| Dimensions & Tires | |
| Wheelbase | 65.8 inches 167 cm |
| Weight | 3014 lbs 1367 kg |
| Front tire | 7x16 |
| Rear tire | 12.4x24 |
 Full dimensions and tires ... | |
| Branson 3515R attachments | |
| front-end loader | |
 Attachment details ... |
| 3515R Serial Number Location | |
 | |
| Serial number plate on the front right side of the main tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 15 Series published in 2019, by Branson |
