John Deere 9R 490

John Deere 9R 490 tractor photo
2021 -
9R Series
Four-wheel Drive (4WD) tractor
Series map:
9R 440
9R 490
9R 540
ManufacturerJohn Deere
Four-wheel Drive (4WD) tractor
Built in Waterloo, Iowa, USA
Original price was $602,796 in 2023
9R 490wheeled 4WD
9RX 490articulated crawler
John Deere 9R 490 Engine
John Deere 13.6L 6-cyl diesel
Fuel tank400 gal
1514.0 L
Exhaust fluid (DEF)31.7 gal
120.0 L
Engine details ...
John Deere 9R 490 Power
Engine (gross)482.8 hp
360.0 kW
Engine (max)531 hp
396.0 kW
PTO (claimed)335 hp
249.8 kW
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic front and rear
Articulated power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
No photos of the John Deere 9R 490 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center pressure/flow compensated
Pressure2900 psi
200.0 bar
Valves4 to 8
Pump flow55 gpm
208.2 lpm
 110 gpmOptOptional
416.4 lpm
SCV flow35 gpm
132.5 lpm
 42 gpm*Optional, 3/4 inch coupler
159.0 lpm
Tractor hitch
Rear TypeIVN/IV
Rear lift (at 24"/610mm)15000 lbs
6804 kg
 20000 lbs
9072 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000 (1.75)
Dimensions & Tires
Wheelbase154 inches
391 cm
Weight45980 lbs
20856 kg
Front tire710/70R42
Rear tire710/70R42
Full dimensions and tires ...
Charging systemalternator
Charging amps250
 330 OptOptional
Battery volts12
9R 490 references literature
9 Series Tractors published in 2022, by John Deere
Operator's Manual 9R Tractors (OMTR118780) published in 2021
