Fiat 411C
|
|
| Production | |
| Manufacturer | Fiat |
| Agricultural Crawler tractor | |
| Variants | |
| 411R | utility |
| 411RB | gasoline engine |
| 411T | tricycle |
| 411C | crawler |
| 421R | orchard |
| 431R | vineyard |
| 441R | four-wheel drive |
| 451C | mountain crawler |
| 481R | high-crop |
| Fiat 411C Engine | |
| Fiat 2.3L 4-cyl diesel | |
 Engine details ... |
| Fiat 411C Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Fiat 411C Power | |
| Engine | 40 hp 29.8 kW |
| Drawbar (tested) | 28.34 hp 21.1 kW |
| PTO (tested) | 37.33 hp 27.8 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 411C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2160 |
| Dimensions & Tracks | |
| Wheelbase | 52 inches 132 cm |
| Weight | 5291 to 5385 pounds |
| 10.2-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual 411C - 451C (603.04.122) published in 1966 |
