Fiat 421R
|
|
| Production | |
| Manufacturer | Fiat |
| Orchard/Vineyard tractor | |
| Variants | |
| 411R | utility |
| 411RB | gasoline engine |
| 411T | tricycle |
| 411C | crawler |
| 421R | orchard |
| 431R | vineyard |
| 441R | four-wheel drive |
| 451C | mountain crawler |
| 481R | high-crop |
| Fiat 421R Engine | |
| FIAT 2.3L 4-cyl diesel | |
 Engine details ... |
| Fiat 421R Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Fiat 421R Power | |
| Engine | 40 hp 29.8 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Manual steering | |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 421R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Clutch | mechanical dry disc |
| Rear PTO Type | 540 |
| Engine RPM | 540@2160 |
| Dimensions & Tires | |
| Wheelbase | 71.3 inches 181 cm |
| Weight | 3087 lbs 1400 kg |
| Front tire | 5.50-16 |
| Rear tire | 11-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| Use e manutenzionoe 411R 421R |
