Massey Ferguson 471


Massey Ferguson 471 tractor photo
2002 - 2006
Model year
400 Series
Utility tractor
Series map:
451
471
481
48.0hp
65.0hp
75.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Utility tractor
Built in Brazil
Massey Ferguson 471 Transmissions
8-speed gear
8-speed partially synchronized
Transmission details ...
Massey Ferguson 471 Power
Engine (net)65 hp
48.5 kW
PTO (claimed)59 hp
44.0 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post foldable ROPS.
Photos
No photos of the Massey Ferguson 471 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel17.4 gal
65.9 L
Hydraulic system11.1 gal
42.0 L
Hydraulics
Typeopen center
Capacity11.1 gal
42.0 L
Pressure2500 psi
172.4 bar
Valves2
Pump flow11 gpm
41.6 lpm
Steering press.1740 psi
120.0 bar
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift (at ends)4630 lbs
2100 kg
Power Take-off (PTO)
Rear PTOlive
 independent OptOptional
Clutch254mm mechanical dry disc
 hydraulic wet disc *With independent PTO option.
Rear PTO Type540 (1.375)
Engine RPM540@1908 (gear)
 540@1789 (shuttle)
Dimensions & Tires
2WD Wheelbase90.2 inches
229 cm
4WD Wheelbase90 inches
228 cm
Weight5578 to 6305 pounds
Front tire7.50-16
2WD Rear tire16.9-30
Full dimensions and tires ...
471 Serial Number Location
Massey Ferguson 471 serial number location
Serial number on the left side of the tractor, below the dashboard.
Electrical
Groundnegative
Charging systemalternator
Charging amps35
Battery CCA750
Battery volts12
References
471 references literature
MF Loaders for Compact & Agricultural Tractors published in 2003, by Massey Ferguson
MF 400 Series Tractor published in 2003, by Massey Ferguson
