John Deere 5100E



John Deere 5100E tractor photo
2013 - 2024
Model year
5E Series
Utility tractor
Series map:
5090E
5100E
90.0hp
100.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price$53,776 (2019 )
$56,498 (2021 )
John Deere 5100E Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5100E Transmissions
12-speed
24-speed
Transmission details ...
John Deere 5100E Power
Engine (gross)100 hp
74.6 kW
PTO (claimed)85 hp
63.4 kW
PTO (tested)90.65 hp
67.6 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockmechanical rear
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the John Deere 5100E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel30 gal
113.6 L
Exhaust fluid (DEF)3.2 gal
12.1 L
Hydraulic system11.5 gal
43.5 L
Hydraulics
Typeopen center
Capacity11.5 gal
43.5 L
Pressure2900 psi
200.0 bar
Valves2 or 3
SCV flow15.9 gpm
60.2 lpm
Total flow22.5 gpm
85.2 lpm
Tractor hitch
Rear TypeII
Controlmechanical top-link draft sensing
Rear lift (at 24"/610mm)3213 lbs
1457 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
 540/1000 OptOptional
Engine RPM540@ 2400
 540E@1716
 1000@2400
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight7275 to 8150 pounds
Front tire12.4-24
Rear tire18.4-30
Full dimensions and tires ...
John Deere 5100E attachments
front-end loader
Attachment details ...
5100E Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5100E references literature
5E Utility Tractors published in 2018, by John Deere
5E Utility Tractors published in 2019, by John Deere
5E Utility Tractors published in 2022, by John Deere
