Kubota M4-061
| | 2019 - |
| M4 Series | | Utility tractor |
|
Series map:
M4-061
M4-071
65.4hp
73.2hp
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Original price was $50,018 in 2019 |
| Kubota M4-061 Power |
| Engine (gross) | 65.4 hp
48.8 kW
|
| PTO (claimed) | 52 hp
38.8 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Kubota M4-061 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 23.8 gal
90.1 L
|
| Hydraulic system | 10.6 gal
40.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10.6 gal
40.1 L
|
| Valves | 2 to 3
|
| Pump flow | 16.7 gpm
63.2 lpm
|
| Steering flow | 6.3 gpm
23.8 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position control and top-link draft sensing
|
| Rear lift (at 24"/610mm) | 3307 lbs
1500 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 130
|
| Battery CCA | 900
|
| Battery volts | 12
|
| References |
 |
| M4-061/M4-071 published in 2019, by Kubota |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 21, 2019 |
