Kubota M4-061
| 2019 - |
M4 Series | Utility tractor |
|
Production |
Manufacturer: | Kubota
|
Type: | Utility tractor
|
Original price: | $50,018 (2019 )
|
Kubota M4-061 Power |
Engine (gross): | 65.4 hp 48.8 kW
|
PTO (claimed): | 52 hp 38.8 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Steering: | power
|
Brakes: | hydraulic wet disc
|
Cab: | Cab standard with air-conditioning.
|
Transmissions: | 12-speed power shuttle
|
| 18-speed creeper
|
Transmission details ... |
Photos |
No photos of the Kubota M4-061 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity |
Fuel: | 23.8 gal 90.1 L
|
Hydraulic system: | 10.6 gal 40.1 L
|
Hydraulics |
Type: | open center
|
Capacity: | 10.6 gal 40.1 L
|
Valves: | 2 to 3
|
Pump flow: | 16.7 gpm 63.2 lpm
|
Steering flow: | 6.3 gpm 23.8 lpm
|
Tractor hitch |
Rear Type: | II/I
|
Control: | position control and top-link draft sensing
|
Rear lift (at 24"/610mm): | 3307 lbs 1500 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | electro-hydraulic
|
Rear RPM: | 540/540E (1.375)
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 130
|
Battery CCA: | 900
|
Battery volts: | 12
|
