Kubota M4-071
| | 2019 - |
| M4 Series | | Utility tractor |
|
Series map:
M4-061
M4-071
65.4hp
73.2hp
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Original price | $48,866 (2018 standard )
|
| $51,852 (2019 deluxe )
|
| Variants |
| M4-071 | standard
|
| M4-071D | deluxe
|
| M4N-071 | narrow profile
|
| Kubota M4-071 Power |
| Engine (gross) | 73.2 hp
54.6 kW
|
| PTO (claimed) | 60 hp
44.7 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Kubota M4-071 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 23.8 gal
90.1 L
|
| Hydraulic system | 10.6 gal
40.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10.6 gal
40.1 L
|
| Valves | 2 to 3
|
| Pump flow | 16.7 gpm
63.2 lpm
|
| Steering flow | 6.3 gpm
23.8 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position control and top-link draft sensing
|
| Rear lift (at 24"/610mm) | 3307 lbs
1500 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear RPM | 540 (1.375)
|
| | 540/540E (1.375)*540E PTO is standard with deluxe trim, optional on standard trim.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 130
|
| Battery CCA | 900
|
| Battery volts | 12
|
| References |
 |
| M4-061/M4-071 published in 2019, by Kubota |
