John Deere 2510 Hi-Crop
|
|
| Production | |
| Manufacturer | John Deere |
| High-Clearance tractor | |
| Built in Waterloo, Iowa, USA | |
| Total built | 139 (total Hi-Crop) |
| 103 (diesel Syncro-Range) | |
| 29 (diesel Power Shift) | |
| 4 (gas Syncro-Range) | |
| 3 (gas Power Shift) | |
| John Deere 2510 Hi-Crop Engines | |
| John Deere 3.0L 4-cyl gasoline | |
| John Deere 3.3L 4-cyl diesel | |
 Engine details ... |
| John Deere 2510 Hi-Crop Transmissions | |
| 8-speed partially synchronized | |
| 8-speed full power shift | |
 Transmission details ... |
| John Deere 2510 Hi-Crop Power |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Open operator station. | |
| Capacity | |
| Fuel | 26 gal 98.4 L |
| Hydraulic system | 11 gal (SyncroRange) 41.6 L |
| 14 gal (PowerShift) 53.0 L | |
| Hydraulics | |||
| Type | closed center constant pressure | ||
| Capacity | 11 gal (SyncroRange) 41.6 L | ||
| 14 gal (PowerShift) 53.0 L | |||
| Pressure | 2250 psi 155.1 bar | ||
| Valves | 1 or 2 | ||
| Oil type |
| ||
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and top-link draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.375) | |
| Engine RPM | 540@2100 |
| 1000@2100 | |
| Front PTO | optional |
| Front PTO Type | 1000 |
| Engine RPM | 1000@2100 |
| Dimensions & Tires | |
| Wheelbase | 92.8 inches 235 cm |
| Weight | 7230 to 7380 pounds |
| Front tire | 7.50-20 |
| Rear tire | 13.6-38 |
 Full dimensions and tires ... | |
| 2510 Hi-Crop Serial Numbers | |
| Location: | Serial number plate on the rear of the John Deere 2510, above the PTO shaft. |
| 1966 | 1000 |
| 1967 | 8958 |
| 1968 | 14291 |
| Final | 16501 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Batteries | 1 (gas) |
| 2 (diesel) | |
| Battery volts | 12 |
| Battery AH | 75 |
| References | |
 | |
| The John Deere 10 Series New Generation Tractors published in 2004, by Hain Publishing | |
| John Deere Tractors for 68 published in 1968 |
