New Holland Workmaster 37

New Holland Workmaster 37 tractor photo
2015 - 2016   Workmaster Series
Compact Utility tractor
Next model:New Holland Workmaster 40
Series back:New Holland Workmaster 33



Manufacturer:New Holland (a part of CNH)

New Holland Workmaster 37 Engine:

   Shibaura 1.5L 3-cyl diesel
full engine details ...


Fuel:7.4 gal [28.0 L]

3-Point Hitch:

Rear Type:I
Control:position control
Rear lift (at ends):1808 lbs [820 kg]
Rear lift (at 24"/610mm):1433 lbs [650 kg]

Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)

Dimensions & Tires:

Wheelbase:67.5 inches [171 cm]
Weight:3067 lbs [1391 kg]
Front tire:7x14
Rear tire:11.2x24
full dimensions and tires ...

New Holland Workmaster 37 attachments:

 front-end loader
all Workmaster 37 attachments ...

Workmaster 37 Serial Numbers:

- Serial numbers unknown -

New Holland Workmaster 37 Power:

Engine:36.2 hp [27.0 kW]
Gear PTO (claimed):29.6 hp [22.1 kW]
Hydro PTO (claimed):28.1 hp [21.0 kW]


Chassis:4x4 MFWD 4WD
Final drives:inboard planetary
Brakes:wet disc
Cab:Two-post folding ROPS.


Type:open center
Valves:1 or 2
Pump flow:8.2 gpm [31.0 lpm]


Charging system:alternator
Charging amps:85
