CaseIH Maxxum 145 MultiController
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Original price | $131,758 (2017 Power shift ) |
| $150,446 (2017 CVT ) | |
| Variants | |
| Maxxum 145 | standard |
| Maxxum 145MC | premium |
| CaseIH Maxxum 145 MultiController Engine | |
| FPT 4.5L 4-cyl diesel | |
 Engine details ... |
| CaseIH Maxxum 145 MultiController Transmissions | |
| 16-speed partial power shift | |
| continuously-variable transmission (CVT) | |
 Transmission details ... |
| CaseIH Maxxum 145 MultiController Power | |
| Engine (gross) | 145 hp 108.1 kW |
| Engine (max) | 175 hp 130.5 kW |
| PTO (claimed) | 120 hp 89.5 kW |
| Drawbar (tested) | 88.4 hp 65.9 kW |
| PTO (tested) | 135.6 hp 101.1 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Maxxum 145 MultiController are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 51.5 gal 194.9 L |
| 57.5 gal*Optional, with auxiliary tank. 217.6 L | |
| 60.8 gal*Optional, max tank. 230.1 L | |
| Exhaust fluid (DEF) | 10.4 gal 39.4 L |
| Hydraulic system | 19.5 gal 73.8 L |
| Hydraulics | |
| Type | pressure flow compensated |
| Capacity | 19.5 gal 73.8 L |
| Rear valves | 3 or 4 |
| Mid valves | 0 to 3 |
| Pump flow | 29.8 gpm 112.8 lpm |
| 33 gpm*With CVT transmission. 124.9 lpm | |
| SCV flow | 25.1 gpm (mechanical) 95.0 lpm |
| 26.5 gpm (electronic) 100.3 lpm | |
| Total flow | 42.4 gpm 160.5 lpm |
| 45.5 gpm*With CVT transmission. 172.2 lpm | |
| Steering flow | 12.4 gpm 46.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| IIIN/II OptOptional | |
| Control | electronic lower-link draft sensing |
| Rear lift (at 24"/610mm) | 6900 lbs 3129 kg |
| 7700 lbsOptOptional 3492 kg | |
| Rear Arms | telescopic link ends |
| Front Hitch | optional |
| Drawbar | Cat. 3 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent OptOptional |
| Clutch | 1000:1895 |
| Front PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 104 inches 264 cm |
| 106.2 inches*With front-axle suspension. 269 cm | |
| Weight | 12500 lbs 5670 kg |
| Front tire | 380/85R28 |
| Rear tire | 460/85R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging amps | 120 |
| 150 OptOptional | |
| 200 OptOptional | |
| Battery CCA | 1300 |
| Battery volts | 12 |
| Battery AH | 176 |
| References | |
 | |
| Maxxum Series Tractors published in 2016, by CaseIH |
