Massey Ferguson 135 Special
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Detroit, Michigan, USA | |
| Variants | |
| 135 Deluxe | premium |
| 135 Special | economy |
| 2135 | industrial tractor |
| Massey Ferguson 135 Special Engines | |
| Continental 2.2L 4-cyl gasoline | |
| Continental 2.4L 4-cyl gasoline | |
| Perkins 2.5L 3-cyl gasoline | |
 Engine details ... |
| Massey Ferguson 135 Special Power | |
| Engine | 45.5 hp 33.9 kW |
| PTO (claimed) | 35 hp 26.1 kW |
| Drawbar (tested) | 33.06 hp 24.7 kW |
| PTO (tested) | 37.82 hp 28.2 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Massey Ferguson 135 Special are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 13.7 gal 51.9 L |
| Hydraulic system | 8 gal 30.3 L |
| Hydraulics | |||
| Capacity | 8 gal 30.3 L | ||
| Pressure | 2800 psi 193.1 bar | ||
| Pump flow | 4.5 gpm 17.0 lpm | ||
| Total flow | 4.8 gpm 18.2 lpm | ||
| Oil type |
| ||
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 2,850 lbs 1292 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1700 |
| Dimensions & Tires | |
| Wheelbase | 72 inches 182 cm |
| Weight | 3075 lbs 1394 kg |
| Front tire | 5.50-16 |
| Rear tire | 12.4-28 |
 Full dimensions and tires ... | |
| 135 Special Serial Numbers | |
| Location: | Serial number on the instrument panel below the steering column. Serial number may also be on the right side of the engine, below the battery tray. |
| 1964 | 641000001 |
| 1965 | 641001909 |
| 1966 | 641014871 |
| 1967 | 9A10001 |
| 1968 | 9A39836 |
| 1969 | 9A63158 |
| 1970 | 9A87325 |
| 1971 | 9A107519 |
| 1972 | 9A128141 |
| 1973 | 9A152025 |
| 1974 | 9A182761 |
| 1975 | 9A207681 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | generator |
| Charging amps | 10 |
| Battery volts | 12 |
| Battery AH | 40 |
| References | |
 | |
| MF 135 / MF 150 Tractors published in 1972, by Massey Ferguson |
