Massey Ferguson 2135
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Industrial tractor | |
| The Massey Ferguson 2135 was the industrial version of the model 135 agricultural tractor. The Turf model of the 2135 used serial number prefix 648. | |
| Massey Ferguson 2135 Engines | |
| Continental 2.2L 4-cyl gasoline | |
| Perkins 2.5L 3-cyl diesel | |
 Engine details ... |
| Massey Ferguson 2135 Transmissions | |
| 6-speed gear | |
| 6-speed manual shuttle | |
 Transmission details ... |
| Massey Ferguson 2135 Power | |
| Engine | 45.5 hp 33.9 kW |
| PTO (claimed) | 34 hp 25.4 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear OptOptional |
| Steering | manual |
| Steering | power OptOptional |
| Drum brakes | |
| Open operator station. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2125 psi 146.5 bar |
| Pump flow | 4.5 gpm (hitch) 17.0 lpm |
| 17 gpm (loader-backhoe) 64.3 lpm | |
| Tractor hitch | |
| Rear Type | I OptOptional |
| Rear lift | 2850 lbs 1292 kg |
| Power Take-off (PTO) | |
| Rear PTO | live OptOptional |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1684 |
| Dimensions & Tires | |
| Wheelbase | 75 inches 190 cm |
| Weight | 3060 to 7150 pounds |
| Front tire | 6.00-16 |
| Rear tire | 12.4-28 |
 Full dimensions and tires ... | |
| Massey Ferguson 2135 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| 2135 Serial Numbers | |
| 1964 | 646000001 |
| 1965 | 646000190 |
| 1966 | 646001465 |
| 1967 | 9A10001 |
| 1968 | 9A39836 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| 2130 & 2135 tractors - equipped for the highway published by Massey Ferguson | |
| MF 2135 Backhoe Loader published in 1968, by Massey Ferguson | |
| MF 2135 Tractor published in 1965, by Massey Ferguson | |
| MF 2135 Tractor Loader published in 1968, by Massey Ferguson | |
| MF 2135 Tractor published in 1968, by Massey Ferguson | |
| MF100/MF200 Industrial Loaders published in 1966, by Massey Ferguson | |
| Installation & Operation of Basic & Auxiliary Hydraulic Systems (690 562 M2) published in 1968 |
