New Holland TS135A
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Utility tractor | |
| Built in Basildon, England | |
| Original price | $58,678 (2003 Dual Command 2WD) |
| $73,051 (2003 AutoShift 4WD) | |
| Variants | |
| MXU135 | similar CaseIH model |
| New Holland TS135A Engine | |
| Iveco 6.7L 6-cyl diesel | |
| Fuel tank | 67.1 gal 254.0 L |
| SuperSteer Fuel tank | 62.3 gal 235.8 L |
 Engine details ... | |
| New Holland TS135A Transmissions | |
| 24-speed two-speed power shift | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| New Holland TS135A Power | |
| Engine (gross) | 135 hp 100.7 kW |
| Engine (max) | 169 hp 126.0 kW |
| PTO (claimed) | 115 hp 85.8 kW |
| Drawbar (tested) | 94.4 hp 70.4 kW |
| PTO (tested) | 127.4 hp 95.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | planetary inboard |
| Differential lock | electro-hydraulic rear |
| front OptOptional | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the New Holland TS135A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed-center load sensing |
| Pressure | 3046 psi 210.0 bar |
| Rear valves | 2 to 4 |
| Mid valves | 2 |
| Pump flow | 29.9 gpm 113.2 lpm |
| SCV flow | 25 gpm 94.6 lpm |
| Steering flow | 10.5 gpm 39.7 lpm |
| Tractor hitch | |
| Rear Type | IIIN/II |
| Rear lift (at 24"/610mm) | 12185 lbs 5527 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| 2WD Wheelbase | 104.4 inches 265 cm |
| Terraglide Wheelbase | 104.8 inches 266 cm |
| SuperSteer Wheelbase | 108.7 inches 276 cm |
| Weight | 10913 lbs 4950 kg |
| Front tire | 11.00-16 |
| 2WD Rear tire | 16.9R38 |
 Full dimensions and tires ... | |
| New Holland TS135A attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
