New Holland TS130A
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Utility tractor | |
| Built in Basildon, England | |
| New Holland TS130A Engine | |
| Iveco 6.7L 6-cyl diesel | |
| Fuel tank | 67.1 gal 254.0 L |
 Engine details ... | |
| New Holland TS130A Transmissions | |
| 24-speed two-speed power shift | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| New Holland TS130A Power | |
| Engine (gross) | 130 hp 96.9 kW |
| PTO (claimed) | 110 hp 82.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the New Holland TS130A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2755 psi 190.0 bar |
| Rear valves | 2 to 4 |
| Mid valves | 2 OptOptional |
| Pump flow | 16.6 gpm 62.8 lpm |
| Total flow | 27.1 gpm 102.6 lpm |
| Steering flow | 10.5 gpm 39.7 lpm |
| Tractor hitch | |
| Rear Type | II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1969 |
| 540E@1546 | |
| 1000@2120 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 104.4 inches 265 cm |
| 4WD Wheelbase | 104.7 inches 265 cm |
| Weight | 9986 to 11265 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 18.4R38 |
 Full dimensions and tires ... | |
| TS130A Serial Numbers | |
| Location: | Serial number decal on the left side of the tractor, on the lower part of the radiator support bracket. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 70 |
| Cab Charging amps | 120 |
| Battery volts | 12 |
| References | |
 | |
| TS-A Delta Tractors published in 2006, by New Holland | |
| Operator's Manual TS-A Series Tractors (82999130) published in 2005 |
