John Deere 2240



John Deere 2240 tractor photo
1976 - 1982
Model year
2040 Series
Utility tractor
Series map:
2040
2240
2440
44.4hp*
55.6hp*
67.4hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $16,000 in 1982
Variants
2240utility
2240-Oorchard
John Deere 2240 Engine
John Deere 2.9L 3-cyl diesel
Fuel tank16.5 gal
62.5 L
Engine details ...
John Deere 2240 Transmissions
8-speed partially synchronized
16-speed two-speed power shift
8-speed power shuttle
Transmission details ...
John Deere 2240 Power
PTO (claimed)50 hp
37.3 kW
Drawbar (tested)39.58 hp
29.5 kW
PTO (tested)50.37 hp
37.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Steeringpower assist
Hydraulic wet disc brakes
Open operator station.
Photos
No photos of the John Deere 2240 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Pressure2250 psi
155.1 bar
Valves1 or 2
Pump flow13 gpm
49.2 lpm
Tractor hitch
Rear TypeII
Controlposition control and lower-link draft sensing
Rear lift (at 24"/610mm)2400 lbs
1088 kg
Power Take-off (PTO)
Rear PTOindependent *Independent PTO with TSS transmission.
 live *Live PTO with two-stage clutch with collar-shift transmission.
Rear PTO Type540
Dimensions & Tires
Wheelbase80.65 inches (straight axle)
204 cm
 74.4 inches (swept axle)
188 cm
Weight4950 lbs
2245 kg
Front tire6.50-16
2WD Rear tire14.9-29
Full dimensions and tires ...
John Deere 2240 attachments
backhoe
Attachment details ...
2240 Serial Number Location
John Deere 2240 serial number location
Serial number tag on the front-right of the John Deere 2240 frame, above the front axle.
2240 Serial Numbers
1976179298
1977221716
1978277267
1979305307
1980337767
1981392292
1982418608

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Batteries1
 2 OptOptional
Battery volts12
References
2240 references literature
Tractors, 40 to 80 HP published in 1981, by John Deere
Tractors 40 to 80 HP published in 1981, by John Deere
John Deere tractors 22 to 50 HP published in 1980
