John Deere 2240 Orchard


John Deere 2240 Orchard tractor photo
1976 - 1982
2040 Series
Orchard/Vineyard tractor
Production
Manufacturer:John Deere
Type:Orchard/Vineyard tractor
Factory:Mannheim, Baden-W├╝rttemberg, Germany
Variants
2240:utility
2240-O:orchard
John Deere 2240 Orchard Power
PTO (claimed):50 hp
37.3 kW
John Deere 2240 Orchard Engine
John Deere 2.9L 3-cyl diesel
Fuel tank:20.6 gal
78.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:power
Brakes:hydraulic wet disc
Cab:Open operator station.
Transmissions:8-speed
 16-speed two-speed power shift
Transmission details ...
Photos
No photos of the John Deere 2240 Orchard are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center
Rear valves:1 or 2
Tractor hitch
Rear Type:II
Power Take-off (PTO)
Rear PTO:independent*Independent PTO used with TSS transmission.
 live*Live PTO with two-stage clutch used with Collar Shift transmission
Rear RPM:540 (1.375)
Dimensions & Tires
Wheelbase:75 inches
190 cm
Weight:4365 lbs
1979 kg
Front tire:6.50-16
Rear tire:14.9-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
