John Deere 6175M
|
|
| Production | |
| Manufacturer | John Deere |
| Row-Crop tractor | |
| Built in Mannheim, Baden-Württemberg, Germany | |
| John Deere 6175M Engine | |
| John Deere 6.8L 6-cyl diesel | |
| Fuel tank | 85 gal 321.7 L |
| Exhaust fluid (DEF) | 5 gal 18.9 L |
 Engine details ... | |
| John Deere 6175M Transmissions | |
| 16-speed four-speed power shift | |
| 20-speed four-speed power shift | |
 Transmission details ... |
| John Deere 6175M Power | |
| Engine (gross) | 175 hp 130.5 kW |
| Engine (max) | 185 hp 138.0 kW |
| PTO (claimed) | 142 hp 105.9 kW |
| Drawbar (tested) | 140.4 hp 104.7 kW |
| PTO (tested) | 167.4 hp 124.8 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditoning. | |
| Photos | |
| No photos of the John Deere 6175M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed-center pressure-and-flow compensated |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 3 OptOptional |
| Mid valves | 3 OptOptional |
| Pump flow | 30 gpm 113.6 lpm |
| SCV flow | 26.4 gpm 99.9 lpm |
| Tractor hitch | |
| Rear Type | IIIN/II |
| Control | electronic lower-link draft sensing |
| Rear lift | 10696 lbs 4851 kg |
| Drawbar | Cat. 2 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 (1.375) |
| 540 | |
| Engine RPM | 540@1932 |
| 1000@1932 | |
| Dimensions & Tires | |
| Wheelbase | 110.2 inches 279 cm |
| Weight | 15664 lbs 7105 kg |
| Front tire | 10.00-16 |
| 2WD Rear tire | 460/85R38 |
 Full dimensions and tires ... | |
| John Deere 6175M attachments | |
| front-end loader | |
 Attachment details ... |
| 6175M Serial Number Location | |
 | |
| Serial number plate on the right side of the tractor frame, above and to the rear of the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| 200 OptOptional | |
| Charging volts | 14 |
| Battery volts | 12 |
