Tractors > John Deere > 6195M

John Deere 6195M



John Deere 6195M tractor photo
2015 - 2025
Model year
6M Series
Row-Crop tractor
Series map:
6175M
6195M
175.0hp
195.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6195M Engine
John Deere 6.8L 6-cyl diesel
Fuel tank85 gal
321.7 L
Exhaust fluid (DEF)5 gal
18.9 L
Engine details ...
John Deere 6195M Transmissions
16-speed four-speed power shift
20-speed four-speed power shift
Transmission details ...
John Deere 6195M Power
Engine (gross)195 hp
145.4 kW
Engine (max)206 hp
153.6 kW
PTO (claimed)158 hp
117.8 kW
Drawbar (tested)157 hp
117.1 kW
PTO (tested)182.9 hp
136.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditoning.
Photos
No photos of the John Deere 6195M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center pressure-and-flow compensated
Pressure2900 psi
200.0 bar
Rear valves3 OptOptional
Mid valves3 OptOptional
Pump flow30 gpm
113.6 lpm
SCV flow26.4 gpm
99.9 lpm
Tractor hitch
Rear TypeIIIN/II
Controlelectronic lower-link draft sensing
Rear lift10696 lbs
4851 kg
DrawbarCat. 2
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
 540
Engine RPM540@1932
 1000@1932
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight15664 lbs
7105 kg
Front tire10.00-16
2WD Rear tire460/85R38
Full dimensions and tires ...
John Deere 6195M attachments
front-end loader
Attachment details ...
6195M Serial Number Location
John Deere 6195M serial number location
Serial number plate on the right side of the tractor frame, above and to the rear of the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 200 OptOptional
Charging volts14
Battery volts12
