John Deere 4049M


John Deere 4049M tractor photo
2014 -
4M Series
Compact Utility tractor
4320
Series:4044M4049M4052M
Production
Manufacturer:John Deere
Type:Compact Utility tractor
Factory:Augusta, Georgia, USA
Variants
4049M:base model
4049R:deluxe model
John Deere 4049M Power
Engine:49 hp
36.5 kW
John Deere 4049M Engine
Yanmar 2.0L 4-cyl diesel
Fuel tank:13 gal
49.2 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:planetary
Differential lock:mechanical rear
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post folding ROPS.
Transmissions:12-speed power shuttle
 hydrostatic
Transmission details ...
Photos
No photos of the John Deere 4049M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2500 psi
172.4 bar
Pump flow:10.2 gpm
38.6 lpm
Total flow:15.9 gpm
60.2 lpm
Steering flow:5.7 gpm
21.6 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):3130 lbs
1419 kg
Rear lift (at 24"/610mm):2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@2400
Dimensions & Tires
Wheelbase:73 inches
185 cm
Weight:3770 lbs
1710 kg
Front tire:8.00-16
Rear tire:13.6-28
Full dimensions and tires ...
4049M Serial Numbers
Location:Serial number plate on the right side of the 4049M tractor frame, above the front axle.
photo of 4049M serial number

Electrical
Ground:negative
Charging system:alternator
Charging amps:75
Battery CCA:770
Battery volts:12
