Tractors > John Deere > 4049R

John Deere 4049R



John Deere 4049R tractor photo
2014 -
4R Series
Compact Utility tractor
Series map:
4044R
4049R
4052R
42.5hp
49.0hp
50.8hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Variants
4049Mbase model
4049Rdeluxe model
John Deere 4049R Engine
Yanmar 2.0L 4-cyl diesel
Engine details ...
John Deere 4049R Transmissions
12-speed power shuttle
hydrostatic
Transmission details ...
John Deere 4049R Power
Engine (gross)49 hp
36.5 kW
Gear PTO (claimed)34.6 hp
25.8 kW
Hydro PTO (claimed)33.6 hp
25.1 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the John Deere 4049R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
ROPS Fuel13 gal
49.2 L
Cab Fuel13.8 gal
52.2 L
Hydraulic system12.5 gal
47.3 L
Hydraulics
Typeopen center
Capacity12.5 gal
47.3 L
Pressure2500 psi
172.4 bar
Pump flow10.2 gpm
38.6 lpm
Total flow15.9 gpm
60.2 lpm
Steering flow5.7 gpm
21.6 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)3130 lbs
1419 kg
Rear lift (at 24"/610mm)2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2600
 540E@1750
Dimensions & Tires
Wheelbase73 inches
185 cm
Weight3770 lbs
1710 kg
Front tire8.00-16
Rear tire13.6-28
Full dimensions and tires ...
John Deere 4049R attachments
front-end loader
backhoe
Attachment details ...
4049R Serial Number Location
John Deere 4049R serial number location
Serial number plate on the right side of the 4049R tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps75
Battery CCA770
Battery volts12
References
4049R references literature
Compact Utility Tractors published in 2016, by John Deere
