CaseIH Steiger 500


CaseIH Steiger 500 tractor photo
2011 - 2023
Model year
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 470
Steiger 500
Steiger 540
470.0hp
500.0hp
535.0hp
Production
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $406,361 in 2015
Variants
500wheeled tractor
500RTrow-crop crawler
500QTcrawler
T9.565similar New Holland model
CaseIH Steiger 500 Engine
FPT 12.9L 6-cyl diesel
Fuel tank310 gal
1173.4 L
Exhaust fluid (DEF)66 gal
249.8 L
Engine details ...
CaseIH Steiger 500 Power
Engine500 hp
372.9 kW
PTO (claimed)435 hp
324.4 kW
Drawbar (tested)416.19 hp
310.4 kW
PTO (tested)507.22 hp
378.2 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Steeringhydraulic articulated
Brakeshydraulic wet disc
 engine brake OptOptional
Trailer brakeshydraulic OptOptional
Surveyor Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensated
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpm*High Flow option
215.7 lpm
 113 gpm*TwinFlow option
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)19621 lbs
8900 kg
Rear Armsquick coupler
DrawbarCat. 4
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@1998 (early)
 1000@1811 (late)
Dimensions & Tires
Wheelbase154 inches
391 cm
Weight43855 lbs
19892 kg
Front tire710/70R42
Rear tire710/70R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA1000
Battery volts12
References
Steiger 500 references literature
Steiger 370-620 Tractors published in 2014, by CaseIH
