CaseIH Farmall 130A
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Original price | $68,708 (2015 ROPS 2WD ) |
| $85,006 (2015 Cab 4WD ) | |
| CaseIH Farmall 130A Engine | |
| FPT 4.5L 4-cyl diesel | |
| Fuel tank | 56.8 gal 215.0 L |
| Exhaust fluid (DEF) | 7.9 gal 29.9 L |
 Engine details ... | |
| CaseIH Farmall 130A Transmissions | |
| 8-speed power shuttle | |
| 8-speed mechanical shuttle | |
| 16-speed power shuttle | |
 Transmission details ... |
| CaseIH Farmall 130A Power | |
| Engine | 130 hp 96.9 kW |
| PTO (claimed) | 105 hp 78.3 kW |
| Drawbar (tested) | 94.17 hp 70.2 kW |
| PTO (tested) | 117.69 hp 87.8 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Two-post ROPS. Cab available with air-conditioning. |
| Hydraulics | |
| Type | open center with closed-center load-sensing remotes |
| Valves | 2 to 4 |
| Pump flow | 22 gpm 83.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | draft sensing |
| Rear lift (at 24"/610mm) | 7200 lbs 3265 kg |
| Dimensions & Tires | |
| 2WD Wheelbase | 95.7 inches 243 cm |
| 4WD Wheelbase | 104 inches 264 cm |
| Weight | 9660 to 10605 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 18.4x34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
| References | |
 | |
| Farmall 110A-140A Tier 4B/Final Tractor Specifications published in 2015, by CaseIH | |
| Farmall Utility Series Tractors published in 2021, by CaseIH |
