Iseki TA320
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Variants | |
| TA320F | 4WD |
| Iseki TA320 Engine | |
| Isuzu 1.5L 4-cyl diesel | |
| Fuel tank | 12.7 gal 48.1 L |
 Engine details ... | |
| Iseki TA320 Power | |
| Engine | 32 hp 23.9 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Open operator station. |
| Photos | |
| No photos of the Iseki TA320 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 564@2800 |
| 705@2800 | |
| 837@2800 | |
| 1308@2800 | |
| Dimensions & Tires | |
| Wheelbase | 73 inches 185 cm |
| Weight | 3109 to 3384 pounds |
| Front tire | 6.00-16 |
| 2WD Rear tire | 13.6-26 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Landleader published in 1987, by Iseki | |
| Operator's Manual Landleader 290 - 320 (1564-912-001-3) |
