CaseIH Maxxum 120
| | 2007 - 2014 |
|
| Maxxum Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | CaseIH (a part of CNH)
|
| Row-Crop tractor |
| Built in Basildon, England |
| Original price was $87,799 in 2011 |
| CaseIH Maxxum 120 Power |
| Engine (gross) | 129 hp
96.2 kW
|
| PTO (claimed) | 100 hp
74.6 kW
|
| Drawbar (tested) | 81.0 hp
60.4 kW
|
| PTO (tested) | 117.9 hp
87.9 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| | pneumatic OptOptional
|
| Cab standard with air-conditioning. |
| Photos |
| No photos of the CaseIH Maxxum 120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center PFC
|
| Valves | 2 to 4
|
| Pump flow | 26.5 gpm
100.3 lpm
|
| Total flow | 37 gpm
140.0 lpm
|
| Steering flow | 10.5 gpm
39.7 lpm
|
| Tractor hitch |
| Rear Type | 2/3N
|
| Control | electronic draft control
|
| Rear lift | 9,620 lbs
4363 kg
|
| Front Hitch | II OptOptional
|
| Front lift | 8157 lbs
3700 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@1969
|
| | 540E@1546
|
| | 1000@2120
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000
|
| Engine RPM | 1000@2120
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| Battery CCA | 960
|
| Battery volts | 12
|
| References |
 |
| Maxxum Series Tractors 90-120 PTO HP published in 2008, by CaseIH |
| Maxxum Series 101-141HP Rated Power published in 2010, by CaseIH |
