Challenger MT285
| | 2003 - 2005 |
| MT200 Series | | Compact Utility tractor | | Iseki built |
|
| Production |
| Distributor | Challenger (a part of AGCO)
|
| Manufacturer | Iseki
|
| Compact Utility tractor |
| Built in Matsuyama, Japan |
| Variants |
| 1440 | similar Massey Ferguson model
|
| Challenger MT285 Power |
| Engine (gross) | 40.1 hp
29.9 kW
|
| Gear PTO (claimed) | 32.4 hp
24.2 kW
|
| Hydro PTO (claimed) | 31.7 hp
23.6 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Hydraulics |
| Type | open center
|
| Pressure | 2130 psi
146.9 bar
|
| Pump flow | 7.7 gpm
29.1 lpm
|
| Total flow | 12.2 gpm (gear)
46.2 lpm
|
| | 9.6 gpm (hydro)
36.3 lpm
|
| Steering flow | 4.5 gpm
17.0 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| | draft control OptOptional
|
| Rear lift (at ends) | 2,755 lbs (gear)
1249 kg
|
| | 2,866 lbs (hydro)
1300 kg
|
| Rear lift (at 24"/610mm) | 2,100 lbs (gear)
952 kg
|
| | 1,940 lbs (hydro)
879 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent OptOptional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| MT200 - Serious Machines with big tractor performance published in 2002, by AGCO |
