Challenger MT275
|
|
| Production | |
| Distributor | Challenger (a part of AGCO) |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Built in Matsuyama, Japan | |
| Challenger MT275 Engine | |
| Iseki 1.5L 3-cyl diesel | |
 Engine details ... |
| Challenger MT275 Transmission | |
| 8-speed mechanical shuttle | |
 Transmission details ... |
| Challenger MT275 Power | |
| Engine (gross) | 40.1 hp 29.9 kW |
| PTO (claimed) | 32.4 hp 24.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
 | |
 Challenger MT275 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2130 psi 146.9 bar |
| Pump flow | 7.7 gpm 29.1 lpm |
| Total flow | 12.2 gpm 46.2 lpm |
| Steering flow | 4.5 gpm 17.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| draft control OptOptional | |
| Rear lift (at ends) | 2,755 lbs 1249 kg |
| Rear lift (at 24"/610mm) | 2,100 lbs 952 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 68.5 inches 173 cm |
| Weight | 3,107 lbs 1409 kg |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Challenger MT275 attachments | |
| 72" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MT200 - Serious Machines with big tractor performance published in 2002, by AGCO |
