J.I. Case 410
| | 1955 - 1957 |
| 400 Series | | Standard-tread tractor |
|
Series map:
410
55.6hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | J.I. Case
|
| Standard-tread tractor |
| Built in Racine, Wisconsin, USA |
| Total built | 1,527
|
| Variants |
| 400 | diesel standard
|
| 401 | diesel row-crop
|
| 402 | diesel vineyard
|
| 403 | diesel high-crop
|
| 405 | diesel orchard
|
| 410 | gasoline standard
|
| 411 | gas row-crop
|
| 413 | gas high-crop
|
| 420 | diesel industrial
|
| 425 | gas industrial
|
| J.I. Case 410 Power |
| Belt (claimed) | 50 hp
37.3 kW
|
| Plows | 4 (14-inch)
|
| Mechanical |
| Two-wheel drive |
| Final drives | bull gear
|
| Steering | manual
|
| | power optional
|
| Open operator station. |
| Capacity |
| Fuel | 21 gal
79.5 L
|
| Aux. fuel | 1 gal
3.8 L
|
| Hydraulic system | 2.6 gal
9.8 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 2.6 gal
9.8 L
|
| Pump flow | 12 gpm
45.4 lpm
|
| Tractor hitch |
| Type | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | mechanical wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 558@1500
|
| 410 Serial Number Location |
 |
| Top-right of instrument panel. |
| Belt Pulley |
| Diameter | 10.5 inches
26 cm
|
| Width | 7.25 inches
18 cm
|
| RPM | 1166
|
| Speed | 3205 ft/min
976.88 meters/min
|
| Electrical |
| Ground | negative
|
| Charging system | generator
|
| Battery volts | 6
|
| Battery AH | 150
|
| Battery Group | 4
|
| References |
 |
| All New "400" published in 1955, by J.I. Case |
| Dealer's Service Manual "400" Series Tractors and Engines (5692) published in 1955 |
| Operator's Instruction Manual 400 Series Spark-Ignition Tractors (5689) published in 1957 |
