J.I. Case 402
|
|
| Production | |
| Manufacturer | J.I. Case |
| Orchard/Vineyard tractor | |
| Built in Racine, Wisconsin, USA | |
| Total built | 81 |
| The Case 402 was a diesel-powered grove-orchard tractor in the 400 series. The 402 was only offered with a swinging drawbar, the model 405 was the orchard model with an Eagle Hitch. | |
| Variants | |
| 400 | diesel standard |
| 401 | diesel row-crop |
| 402 | diesel vineyard |
| 403 | diesel high-crop |
| 405 | diesel orchard |
| 412 | gasoline orchard |
| 420 | diesel industrial |
| J.I. Case 402 Engine | |
| J.I. Case 4.1L 4-cyl diesel | |
 Engine details ... |
| J.I. Case 402 Power | |
| Belt (claimed) | 50 hp 37.3 kW |
| Plows | 4 (14-inch) |
| Mechanical | |
| Two-wheel drive | |
| Steering | manual |
| power optional | |
| Mechanical dry discs brakes | |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 402 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 21 gal 79.5 L |
| Hydraulic system | 2.25 gal 8.5 L |
| Hydraulics | |
| Capacity | 2.25 gal 8.5 L |
| Pressure | 600 psi 41.4 bar |
| Valves | 2 |
| Total flow | 12 gpm 45.4 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 82 inches 208 cm |
| Front tire | 6.00-16 |
| Rear tire | 13-26 |
 Full dimensions and tires ... | |
| Belt Pulley | |
| Diameter | 10.5 inches 26 cm |
| Width | 7.25 inches 18 cm |
| RPM | 1128 |
| Speed | 3101 ft/min 945.18 meters/min |
| Electrical | |
| Ground | negative |
| Charging system | generator |
| Charging volts | 12 |
| Batteries | 2 |
| Battery volts | 6 |
| Battery AH | 150 |
| References | |
 | |
| All New "400" published in 1955, by J.I. Case | |
| Operator's Instruction Manual 400 Series Diesel Tractors (5688) published in 1954 | |
| Dealer's Service Manual "400" Series Tractors and Engines (5692) published in 1955 |
