John Deere 3350


John Deere 3350 tractor photo
1986 - 1993
3050 Series
Utility tractor
Series:305033503650
Production
Manufacturer:John Deere
Type:Utility tractor
Factories:Mannheim, Baden-W├╝rttemberg, Germany
 Rosario, Argentina
John Deere 3350 Power
Engine:100 hp
74.6 kW
PTO (claimed):91.12 hp
67.9 kW
John Deere 3350 Engine
John Deere 5.9L 6-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:planetary
Differential lock:mechanical rear
Steering:power
Brakes:hydraulic wet disc
Cab:Sound-Gard (SG2) Cab standard with optional air-conditioning. Open operator station in some markets.
Transmissions:16-speed
 8-speed
Transmission details ...
Capacity
Fuel:32 gal
121.1 L
 45.7 gal
173.0 L *With optional 52L tank.
Hydraulic system:12.94 gal
49.0 L (2WD)
 13.74 gal
52.0 L (4WD)
Hydraulics
Type:closed center constant pressure
Capacity:12.94 gal
49.0 L (2WD)
 13.74 gal
52.0 L (4WD)
Pressure:2698 psi
186.0 bar
Total flow:11.62 gpm
44.0 lpm
Tractor hitch
Rear Type:II/IIIN
2WD Rear lift (at ends):8988 lbs
4076 kg
4WD Rear lift (at ends):10800 lbs
4898 kg
Front Hitch:II
Front lift (at ends):3594 lbs
1630 kg
 6526 lbs
2960 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Clutch:hydraulic wet disc
Rear RPM:540/1000
Engine RPM:540@2070
1000@2172
Front PTO:independent
Clutch:hydraulic wet disc
Front RPM:1000
Engine RPM:1000@2172
Dimensions & Tires
2WD Wheelbase:88.6 inches
225 cm
4WD Wheelbase:101.7 inches
258 cm
Weight:9315 to 10880 pounds
Front tire:10.00-16
2WD Rear tire:18.4-38
Full dimensions and tires ...
Electrical
Ground:negative
Charging amps:55
Batteries:2
Battery volts:12
Battery AH:88
