Challenger MT765


Challenger MT765 tractor photo
2002 - 2004
MT700 Series
Agricultural Crawler tractor
Series map:
MT755
MT765
290.0hp
306.0hp
Production
ManufacturerChallenger (a part of AGCO)
Agricultural Crawler tractor
Built in Jackson, Minnesota, USA
Challenger MT765 Engine
Caterpillar 8.8L 6-cyl diesel
Fuel tank118 gal*With 88-inch rear axle
446.6 L
 178 gal*With 120 or 160 inch rear axle.
673.7 L
 208 gal*Optional, depending on machine configuration.
787.3 L
Engine details ...
Challenger MT765 Transmissions
16-speed full power shift
30-speed creeper
Transmission details ...
Challenger MT765 Power
Engine (gross)306 hp
228.2 kW
Drawbar (claimed)245 hp
182.7 kW
PTO (claimed)255 hp
190.2 kW
Drawbar (tested)258.6 hp
192.8 kW
PTO (tested)298.77 hp
222.8 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringelectro-hydraulic
Wet disc brakes
Cab standard with air-conditioning.
Hydraulics
Pressure2900 psi
200.0 bar
Valves4 to 6
Total flow43.5 gpm
164.6 lpm
Tractor hitch
Rear TypeIII
Rear lift16000 lbs
7257 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000 (1.75)
Dimensions & Tracks
Wheelbase96 inches
243 cm
Weight29,520 lbs
13390 kg
Tracks
Full dimensions and tracks ...
MT765 Serial Numbers
Location:On main tractor frame, front left side.
2002AMS20000
2003AMS30000
2004AMS40000

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps160
Battery volts12
