Challenger MT755


Challenger MT755 tractor photo
2002 - 2004
MT700 Series
Agricultural Crawler tractor
Series:MT745MT755MT765
MT755B
Production
Manufacturer:Challenger (a part of AGCO)
Type:Agricultural Crawler tractor
Factory:Jackson, Minnesota, USA
Challenger MT755 Power
Engine (gross):290 hp
216.3 kW
Drawbar (claimed):226 hp
168.5 kW
PTO (claimed):235 hp
175.2 kW
Drawbar (tested):202.94 hp
151.3 kW
PTO (tested):270.23 hp
201.5 kW
power test details ...
Challenger MT755 Engine
Caterpillar 8.8L 6-cyl diesel
Fuel tank:118 gal
446.6 L *With 88-inch rear axle
 178 gal
673.7 L *With 120 or 160 inch rear axle.
 208 gal
787.3 L *Optional, depending on machine configuration.
Engine details ...
Mechanical
Chassis:crawler
Steering:electro-hydraulic
Brakes:wet disc
Cab:Cab standard with air-conditioning.
Transmissions:16-speed full power shift
 30-speed creeper
Transmission details ...
Photos
No photos of the Challenger MT755 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2900 psi
200.0 bar
Valves:4 to 6
Total flow:43.5 gpm
164.6 lpm
Tractor hitch
Rear Type:III
Rear lift:16000 lbs
7257 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000 (1.75)
Dimensions & Tracks
Wheelbase:96 inches
243 cm
Weight:29,540 lbs
13399 kg
tracks
Full dimensions and tracks ...
MT755 Serial Numbers
Location:On main tractor frame, front left side.
2002:ALM20000
2003:ALM30000
2004:ALM40000

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:160
Battery volts:12
