Challenger MT755B
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Agricultural Crawler tractor | |
| Built in Jackson, Minnesota, USA | |
| Challenger MT755B Engine | |
| Caterpillar 8.8L 6-cyl diesel | |
| Fuel tank | 118 gal 446.6 L |
| 178 gal (wide) 673.7 L | |
| 208 gal (optional) 787.3 L | |
 Engine details ... | |
| Challenger MT755B Transmission | |
| 16-speed full power shift | |
 Transmission details ... |
| Challenger MT755B Power | |
| Engine (gross) | 301 hp 224.5 kW |
| PTO (claimed) | 245 hp 182.7 kW |
| Drawbar (tested) | 213.58 hp 159.3 kW |
| PTO (tested) | 315.95 hp 235.6 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Steering | electro-hydraulic power |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Challenger MT755B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed-center PFC |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 4 to 6 |
| Pump flow | 43.5 gpm 164.6 lpm |
| Tractor hitch | |
| Rear Type | IIIN/III |
| Rear lift | 16000 lbs 7257 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| Dimensions & Tracks | |
| Wheelbase | 96 inches 243 cm |
| Weight | 31075 lbs 14095 kg |
| 16-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 185 |
| Batteries | 2 |
| Battery CCA | 1000 |
| Battery volts | 12 |
| References | |
 | |
| Challenger MT700B Series published in 2005, by AGCO |
