McCormick Intl XTX185
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl XTX185 Engine | |
| Iveco 6.7L 6-cyl diesel | |
| Fuel tank | 91.7 gal 347.1 L |
 Engine details ... | |
| McCormick Intl XTX185 Transmissions | |
| 32-speed 8-speed power shift | |
| 48-speed | |
 Transmission details ... |
| McCormick Intl XTX185 Power | |
| Engine | 171 hp 127.5 kW |
| Engine (boost) | 183 hp 136.5 kW |
| Drawbar (tested) | 141.1 hp 105.2 kW |
| PTO (tested) | 178.02 hp 132.7 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the McCormick Intl XTX185 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Valves | 3 or 4 |
| Pump flow | 29.1 gpm 110.1 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift (at ends) | 24144 lbs 10951 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 113.1 inches 287 cm |
| Weight | 17739 lbs 8046 kg |
| Front tire | 480/70R30 |
| Rear tire | 20.8R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
| References | |
 | |
| XTX - XtraSpeed published in 2005, by McCormick | |
| XTX - XtraSpeed published in 2005, by McCormick |
