McCormick Intl XTX165
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl XTX165 Engine | |
| Iveco 6.7L 6-cyl diesel | |
| Fuel tank | 79 gal 299.0 L |
 Engine details ... | |
| McCormick Intl XTX165 Transmissions | |
| 32-speed 8-speed power shift | |
| 48-speed partial power shift | |
 Transmission details ... |
| McCormick Intl XTX165 Power | |
| Engine | 162 hp 120.8 kW |
| Engine (boost) | 171 hp 127.5 kW |
| PTO (claimed) | 147 hp 109.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with heat and air-conditioning. Optional hydraulic suspension. |
| Photos | |
| No photos of the McCormick Intl XTX165 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Valves | 3 or 4 |
| Pump flow | 29.1 gpm 110.1 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 17637 lbs 8000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 108 inches 274 cm |
| Weight | 14,330 lbs 6500 kg |
| Rear tire | 600/65R38 |
 Full dimensions and tires ... | |
| XTX165 Serial Numbers | |
| Location: | Serial number plate in the lower-right side of the cab, below the dashboard. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| XTX - XtraSpeed published in 2005, by McCormick |
