McCormick Intl XTX165


McCormick Intl XTX165 tractor photo
2008 - ????
Series:XTX145XTX165
Production
Manufacturer:McCormick Intl
McCormick Intl XTX165 Power
Engine:162 hp
120.8 kW
PTO (claimed):147 hp
109.6 kW
McCormick Intl XTX165 Engine
6.7L 6-cyl diesel
Fuel tank:79 gal
299.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Brakes:wet disc
Cab:Cab standard with heat and air-conditioning. Optional hydraulic suspension.
Transmissions:32-speed partial power shift
 48-speed partial power shift
Transmission details ...
Photos
No photos of the McCormick Intl XTX165 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center
Valves:1 to 5
Total flow:29 gpm
109.8 lpm
Tractor hitch
Rear lift:17,637 lbs
8000 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:108 inches
274 cm
Weight:14,330 lbs
6500 kg
Rear tire:600/65R38
Full dimensions and tires ...
