John Deere 8210
| 1999 - 2002 |
8000 Ten Series | Row-Crop tractor |
|
Series map:
8110
8210
8310
183.3hp*
205.6hp*
227.8hp*
*Estimated engine power for comparison only.
Production |
Manufacturer | John Deere
|
Row-Crop tractor |
Built in Waterloo, Iowa, USA |
Variants |
8210 | wheeled tractor
|
8210T | crawler tractor
|
John Deere 8210 Power |
PTO (claimed) | 185 hp 138.0 kW
|
Mechanical |
Drive | 4x2 2WD
|
  | 4x4 MFWD 4WD (optional)
|
Power steering |
Hydraulics |
Type | closed center PFC
|
Valves | 3 to 5
|
Pump flow | 30 gpm 113.6 lpm
|
Tractor hitch |
Rear Type | III, IIIN
|
Rear lift | 10,400 lbs 4717 kg
|
  | 14,165 lbsOptOptional 6425 kg
|
Power Take-off (PTO) |
Rear PTO | independent
|
Rear PTO Type | 1000
|
  | 540/1000 OptOptional
|
8210 Serial Numbers |
Location: | Serial number plate on the rear of the John Deere 8210.
|
Electrical |
Charging amps | 140
|
Batteries | 2
|
Battery CCA | 1,850
|
Battery volts | 12
|
References |
 |
8000/8000T TEN Series Tractors Product Information Handbook published in 1999, by John Deere |
